ESP-wroom-32 CP2102 Wifi+BT
Deska je osazena vysoce integrovaným a výkoným 32 bitovým mikroprocesorem v kombinaci s USB rozharním CP2102.
Obsahuje Wifi a Bluetooth konektivitu a je kompatibilní s NodeMCU.
Features
240 MHz dual core Tensilica LX6 microcontroller with 600 DMIPS
Integrated 520 KB SRAM
Integrated 802.11 b/g/n HT40 Wi-Fi transceiver, baseband, stack and LWIP
Integrated dual mode Bluetooth (classic and BLE)
4 MB flash, memory-mapped to the CPU code space
2.3V to 3.6V operating voltage
-40°C to +125°C operating temperature
On-board PCB antenna or IPEX connector for external antenna
Ultra-low noise analog amplifier
Sensors
Hall sensor
10x capacitive touch interfaces
32 kHz crystal oscillator
34x GPIO
3 x UARTs, including hardware flow control
3 x SPI
2 x I2S
12 x ADC input channels
2 x DAC
2 x I2C
PWM/timer input/output available on every GPIO pin
OpenOCD debug interface with 32 kB TRAX buffer
SDIO master/slave 50 MHz
Supports external SPI flash up to 16 MB
SD-card interface support
Security Related
WEP, WPA/WPA2 PSK/Enterprise
Hardware accelerated encryption: AES/SHA2/Elliptical Curve Cryptography/RSA-4096
Performance
Supports sniffer, Station, SoftAP and Wi-Fi direct mode
Max data rate of 150 Mbps@11n HT40, 72 Mbps@11n HT20, 54 Mbps@11g, and 11
Mbps@11b
Maximum transmit power of 19.5 dBm@11b, 16.5 dBm@11g, 15.5 dBm@11n
Minimum receiver sensitivity of -98 dBm
135 Mbps UDP sustained throughput
5 µA power consumption in deep sleep
Doplňkové parametry
Kategorie: | ESP wifi a BT |
---|---|
MCU: | ESP32 Wroom |
Architektura jádra: | 32bit |
Počet jader: | 2 |
Clock speed: | 240MHz |
Pracovní napětí: | 3,3V |
Napájecí napětí Max: | 5,5V |
Flash: | 4MB |
SRAM: | 520kB |
Digital I/O: | 34 |
PWM: | 34 |
I2C: | 2 |
SPI: | 3 |
UART: | 3 |
ADC: | 12 |
DAC: | 2 |
Kapacitních kanálů: | 10 |
Wifi: | 1 |
BlueTooth: | BT |
USB převodník: | CP2102 |
USB konektor: | Micro |
